15.6-inch display specifications
Metric U.S.
Dimensions
Height 19.6 cm 7.72 in
Width 34.7 cm 13.66 in
Diagonal 39.8 cm 15.67 in
Number of colors Up to 16.8 million
Contrast ratio 200:1 (typical)
Brightness 200 nits (typical)
Pixel resolution
Pitch 0.197 × 0.197 mm
Format 1366 × 768
Configuration RGB vertical stripe
Backlight LED
Character display 80 × 25
Total power consumption 2.0 W
Viewing angle ±65° horizontal, ±50° vertical (typical)
88 Chapter 6 Specifications
