Item Component Spare part number
(6a) TouchPad cable
(6b) Optical drive connector cable
(6c) Hard drive connector cable
NOTE: See
Cable Kit on page 23 for more Cable Kit spare part information.
(7) USB board (includes cable) 646128-001
(8) Power connector cable 646121-001
Plastics Kit, includes: 646131-001
(9a) Hard drive compartment cover (includes one captive screw, secured by a C-clip)
(9b) Memory module/wireless module compartment cover (includes one captive screw, secured by a C-clip)
NOTE: See
Plastics Kit on page 26 for more Plastics Kit spare part information.
(10) Speaker Kit (includes left and right speakers and cable) 647315-001
(11) System board (includes replacement thermal material):
For use only with computer models equipped with an AMD E450 1.65-GHz processor
(dual core, 18 W) and a graphics subsystem with UMA video memory
657323-001
For use only with computer models equipped with an AMD E350 1.60-GHz processor
(dual core, 18 W) and a graphics subsystem with UMA video memory
647320-001
For use only with computer models equipped with an AMD E300 1.30-GHz processor
(dual core, 18 W) and a graphics subsystem with UMA video memory
657324-001
For use only with computer models equipped with an AMD E240 1.50-GHz processor
(single core, 18 W) and a graphics subsystem with UMA video memory
647322-001
For use only with computer models equipped with an AMD C50 1.00-GHz processor
(1.0-MB L2 cache, dual core, 9 W) and a graphics subsystem with
UMA video memory
653985-001
For use only with computer models equipped with an Intel Core i5 or i3 processor
and a graphics subsystem with discrete video memory
646179-001
For use only with computer models equipped with an Intel Core i5 or i3 processor
and a graphics subsystem with UMA video memory
646177-001
For use only with computer models equipped with an Intel Pentium processor and a
graphics subsystem with discrete video memory
646176-001
For use only with computer models equipped with an Intel Pentium processor and a
graphics subsystem with UMA video memory
646175-001
For use only with computer models equipped with an Intel Celeron processor and a
graphics subsystem with UMA video memory
646174-001
Thermal Material Kit (includes replacement thermal paste and pads):
For use only with computer models equipped with an AMD processor 650277-001
For use only with computer models equipped with an Intel processor 646135-001
(12) RTC battery (includes cable and double-sided tape) 646132-001
(13) Processor (includes replacement thermal material):
Intel Core i5-2450M 2.50-GHz processor (1333-MHz FSB, 3.0-MB L3 cache,
dual core, 35 W)
676359-001
Computer major components 19
