Spare part number Description
646128-001 USB board (includes cable)
646129-001 Power button board (includes cable)
646130-001 TouchPad button board (includes bracket and cable)
646131-001 Plastics Kit (includes hard drive compartment cover and memory module/wireless module
compartment cover)
NOTE: See
Plastics Kit on page 26 for more Plastics Kit spare part information.
646132-001 RTC battery (includes cable and double-sided tape)
646133-001 Screw Kit
646134-001 Display Screw Kit (includes Mylar screw covers and screws)
646135-001 Thermal Material Kit for use only with computer models equipped with an Intel processor
(includes replacement thermal paste and pads)
646137-001 Top cover (includes TouchPad and TouchPad cable)
646138-001 Webcam/microphone module
646174-001 System board for use only with computer models equipped with an Intel Celeron processor and
a graphics subsystem with UMA video memory (includes replacement thermal material)
646175-001 System board for use only with computer models equipped with an Intel Pentium processor and
a graphics subsystem with UMA video memory (includes replacement thermal material)
646176-001 System board for use only with computer models equipped with an Intel Pentium processor and
a graphics subsystem with discrete video memory (includes replacement thermal material)
646177-001 System board for use only with computer models equipped with an Intel Core i5 or i3 processor
and a graphics subsystem with UMA video memory (includes replacement thermal material)
646179-001 System board for use only with computer models equipped with an Intel Core i5 or i3 processor
and a graphics subsystem with discrete video memory (includes replacement thermal material)
646180-001 Fan/heat sink assembly for use only with computer models equipped with an Intel Pentium
processor and a graphics subsystem with discrete video memory (includes replacement
thermal material)
646181-001 Fan/heat sink assembly for use only with computer models equipped with an Intel Pentium
processor and a graphics subsystem with UMA video memory (includes replacement
thermal material)
646182-001 Fan/heat sink assembly for use only with computer models equipped with an Intel Core i5 or i3
processor and a graphics subsystem with discrete video memory (includes replacement
thermal material)
646183-001 Fan/heat sink assembly for use only with computer models equipped with an Intel Core i5 or i3
processor and a graphics subsystem with UMA video memory (includes replacement
thermal material)
646184-001 Fan/heat sink assembly for use only with computer models equipped with an Intel Celeron
processor and a graphics subsystem with UMA video memory (includes replacement
thermal material)
647315-001 Speaker Kit (includes left and right speakers and cable)
647316-001 Fan/heat sink assembly for use only with computer models equipped with an AMD processor
(includes replacement thermal material)
30 Chapter 3 Illustrated parts catalog
