NOTE: The following illustration shows the fan/heat sink assembly removal process on a computer
model equipped with an Intel processor, the Intel HM65 or HM55 chipset, and a graphics subsystem
with discrete memory.
NOTE: The following illustration shows the fan/heat sink assembly removal process on a computer
model equipped with an Intel processor, the Intel HM65 or HM55 chipset, and a graphics subsystem
with UMA memory.
76 Chapter 4 Removal and replacement procedures
