3. Tilt the system board up to the left slightly (2), and then remove the system board (3).
NOTE: A thermal pad services a component on the bottom of the system board. Replacement
thermal material is included with all system board spare part kits.
Reverse this procedure to install the system board.
106 Chapter 4 Removal and replacement procedures
