Speakers
Table 5-8 Spare part description and number
Description Spare part number
Speaker Kit L23221-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Remove the battery (see Battery on page 29).
Remove the speakers:
1. Disconnect the speaker cable from the system board (1).
2. Lift the tape that secures the speaker cable to the system board (2), and then lift the speakers from the
computer (3).
Reverse this procedure to install the speakers.
38 Chapter 5 Removal and replacement procedures for authorized service provider parts
