User’s Guide B–1
B
Technical Specifications
All specifications represent the typical specifications provided by HP’s component manufacturers; actual performance
may vary either higher or lower.
HP LCD Monitor
Face treatment: Glare polarizer with hard coating
Input Terminals:
■ VGA connector (select models)
■ DVI-D 24-pin D-type connector (select models)
■ HDMI connector (select models)
Specifications
model 2309p
Display Type:
Viewable Image Size:
Tilt:
Maximum Weight (unpacked):
Dimensions (h x w x d):
Maximum Graphics Resolution:
Optimum Graphics Resolution:
Text Mode:
Dot Pitch:
Horizontal Frequency (analog mode):
Vertical Frequency (analog mode):
Environmental Requirements
Temperature (independent of altitude)
Operating Temperature:
Non-operating Temperature:
Relative Humidity (non-condensing):
Operating Humidity:
Non-operating Humidity:
Power Source:
Power Consumption:
Sleep Power Consumption:
TFT LCD active matrix
23 in. (58.4 cm) diagonal
–5° to +25°
13.7 lb (6.2 Kg)
16.2 x 22.6 x 7.9 in. (412 x 573 x 200 mm)
1920 x 1080 @ 60 Hz analog mode
1920 x 1080 @ 60 Hz analog mode
720 x 400
0.30 x 0.30 mm
24 to 94 kHz
50 to 76 Hz
41° to 105° F (5° to 35° C)
–29° to 140° F (–20° to 60° C)
20% to 80%
5% to 95%
100–240Vv, 50/60 Hz
56 watts maximum
<2 watts typical
