Installing the Switch
Installation Procedures
Installing the Switch
■ Installation Location - Before installing the switch, plan its location and
orientation relative to other devices and equipment:
• In the front of the switch, leave at least 7.6 cm (3 inches) of space for
the twisted-pair and fiber-optic cabling.
• In the back of the switch, leave at least 3.8 cm (1 1/2 inches) of space
for the power cord.
• On the sides of the switch, leave at least 7.6 cm (3 inches) for cooling,
except if the switch is installed in an open EIA/TIA rack.
Fiber Optic Cables
Gigabit-SX
(on Gigabit-SX-LC
mini-GBIC)
Multimode fiber-optic cables designed for
Gigabit Ethernet: 62.5/125 μm or 50/125 μm
(core/cladding) diameter, low metal content,
graded-index cables, fitted with LC connectors.
The cables must comply with the ITU-T G.651
and ISO/IEC 793-2 Type A1b or A1a standards.
• 62.5 μm cable:
– 160 MHz*km = 220 meters
– 200 MHz*km = 275 meters
•50 μm cable:
– 400 MHz*km = 500 meters
– 500 MHz*km = 550 meters
Gigabit-LX
(on Gigabit-LX-LC
mini-GBIC)
Single-mode fiber-optic cables designed for
Gigabit Ethernet: 9/125 μm (core/cladding)
diameter, 1310 nm, low metal content cables,
fitted with LC connectors. The cables must
comply with the ITU-T G.652 and ISO/IEC 793-2
Type B1 standards.
The multimode cables specified for the Gigabit-
SX mini-GBIC may also be used, but a mode-
conditioning patch cord may be needed — see
“Mode Conditioning Patch Cord for Gigabit-LX”
on page B-3 for more information.
• single-mode cable = 5 kilometers
• multimode cable = 550 meters
Gigabit-LH
(on Gigabit-LH-LC
mini-GBIC)
Single-mode fiber-optic cables designed for
Gigabit Ethernet and fitted with LC connectors.
• single-mode cable = 70 kilometers
Port Type Cable Type Length Limits

HP 2510-24 Specifications

General

Switching Capacity	8.8 Gbps
Layer	Layer 2
Jumbo Frame Support	Yes
Ports	24 x 10/100
Management	Web-managed
Operating Temperature	0°C to 45°C
Weight	3.08 kg
