Model 3300A Section VII
Table 7-1. Replaceable Parts (Cont’d)
REFERENCE -hp-
DESIGNATOR PART NO TQ DESCRIPTION MFR. MFR. PART NO.
A12Q3, A12Q4 1854-0087 TSTR: Si NPN -hp-
A12Q5 1854-0039 TSTR: Si NPN 2N3053 86684 2N3053
A12Q6 1854-0087 TSTR: Si NPN -hp-
A12Q7, A12Q8 1853-0010 TSTR: Si PNP** -hp-
A12Q9 1853-0001 1 TSTR: Si PNP** -hp-
A12Q10 1853-0010 TSTR: Si PNP** -hp-
A12R1, A12R2 0683-2025 12 R: fxd prec comp 2K ± 5% 1/4 W 01121 CB 2025
A12R3 0683-3935 2 R: fxd prec comp 39K ± 5% 1/4 W 01121 CB 3935
A12R4 0683-6825 1 R: fxd prec comp 6.8K ± 5% 1/4 W 01121 CB 6825
A12R5, A12R6 0689-0275 4 R: fxd prec comp 2.7Ω ± 5% 1 W 01121 CB 0275
A12R7 2100-0865 3 R: var prec comp lin 350Ω ± 30% 1/8 W 71450 XQS-200 obd
A12R8 0698-3341 1 R: fxd prec met flm 1. 91K ± 1% 1/2 W 75042 CEC T-O obd
A12R9 0757-0824 4 R: fxd prec met flm 2. 0K ± 1% 1/2 W 75042 CEC T-O obd
A12R10 0683-3625 2 R: fxd prec comp 3. 6K ± 5% 1/4 W 01121 CB 3625
A12R11 0698-3478 1 R: fxd prec met flm 806Ω ± 1% 1/2 W 75042 CEC T-O obd
A12R12 0683-2025 R: fxd comp 2K ± 5% 1/4 W’ 01121 CB 2025
A12R13 0683-2425 1 R: fxd prec comp 2.4K ± 5% 1/4 W 01121 CB 2425
A12R14 0683-3935 R: fxd comp 39K ± 5% 1/4 W 01121 CB 3935
A12R15 0683-8225 1 R: fxd prec comp 8.2K ± 5% 1/4 W 01121 CB 8225
A12R16, 0689-0275 R: fxd comp 2. 7Ω ± 5% 1 W 01121 CB 0275
A12R17
A12R18 0757-0824 R: fxd prec met flm 2. 0K ± 1% 1/2 W 75042 CEC T-O obd
A12R19 0757-0085 1 R: fxd prec met flm 4. 02K ± 1% 1/2 W 75042 CEC T-O obd
A12R20 2100-1434 1 R: var prec comp 1K ± 30% 1/8 W 71450 XQS 200 obd
A12R21 0683-3625 R: fxd comp 3. 6K ± 5% 1/2 W 75042 CEC T-O obd
A12R22, 0757-0817 2 R: fxd prec met flm 750Ω ± 1% 1/2 W 75042 CEC T-O obd
A12R23
A12R24 0683-1035 1 R: fxd prec comp 10K ± 5% 1/4 W 01121 CB 1035
A12R25 2100-1757 2 R: var ww lin 500Ω ± 10% 1/2 W 75042 Type 506 obd
A12R26 2100-1759 2 R: var ww lin 2K ± 10% 1/2 W 75042 Type 506 obd
A12R27 0757-0728 1 R: fxd met flm 619Ω ± 1% 1/4 W 19701 MF6C T-O obd
A12R28 0757-0178 1 R: fxd met flm 100Ω ± 1% 1/4 W 19701 MF6C T-O obd
1205-0033 7 Heat dissipator-semiconductor for A12Q9 05820 NF-207 obd
A13 03300-66513 Assembly-Integrator Board -hp-
A13C1 0160-0155 1 C: fxd 0.0033
Î
F ± 10% 56289 192P33292
A13C2* thru 0180-0161 16 C: fxd Ta elect 3.3
Î
F ± 20% 35 vdcw 05397 K3R3J35S
A13C4
A13C5* 0160-2009 1 C: fxd mica 820
Î
F ± 5% 72136 RDM15F821J3C
A13C6 0121-0142 2 C: var mica 16-150 pF 175 vdcw 72136 T51410-11
A13C7 0160-3123 1 C: fxd poly 0.01 pF ± 10% 50 vdcw 84412 463UW
A13C8*, Padding capacitor Refer to Section V for
A13C9* replacement
A13C10 0160-3131 1 C: fxd my 0.1
Î
F ± 10% 50 vdcw 84412 463UW
A13C11*, Padding capacitor Refer to Section V for
A13C12* replacement
A13C13 0160-3122 1 C: fxd my 1
Î
F ± 10% 50 vdcw 84412 463UW obd
A13C14*, Padding capacitor Refer to Section V for
A13C15* replacement
A13C16*, Padding capacitor Refer to Section V for
A13C17*, replacement
A13C18*
A13C19 0121-0142 C: var mica 16-150 pF 175 vdcw 72136 T5 1410-11
A13C20 0180-0161 C: fxd Ta elect 3.3
Î
F ± 20% 35 vdcw 05397 K3R3J35S
A13C21 thru 4 Padding capacitor Refer to Section V for
A13C24* replacement
7-3
