Model 3300A Section VII
Table 7-1. Replaceable Parts (Cont’d)
REFERENCE -hp-
DESIGNATOR PART NO TQ DESCRIPTION MFR. MFR. PART NO.
A13CR1 1901-0025 Diode: Si 100 mA at 1V 100 piv 12 pF 07263 FD 2387
A13L1 9170-0016 8 Bead: ferrite 02114 56-590-65/3B
A13L2
A13Q1, A13Q2 1854-0087 TSTR: Si NPN -hp-
A13Q3 1854-0039 TSTR: Si NPN 2N3053 86684 2N3053
A13R1, A13R2 0811-1548 2 R: fxd 2.26K ± 1/4% 1/3 W 15909 DAX1 obd
A13R3 0811-1550 1 R: fxd ww 16. 5K ± 1/4% 2/3 W 15909 DAX2 obd
A13R4 0811-1547 1 R: fxd ww 1. 74K ± 1/4% 1/3 W 15909 DAX1 obd
A13R5 0811-1549 2 R: fxd ww 3. 32K ± 1/4% 1/3 W 15909 DAX1 obd
A13R6, A13R7 0811-1546 2 R: fxd ww 374Ω ± 1/4% 1/3 W 15909 DAX1 obd
A13R8 0811-1549 R: fxd ww 3. 32K ± 1/4% 1/3 W 15909 DAX1 obd
A13R9* 0683-1505 2 R: fxd comp 15Ω ± 5% 1/4 W 01121 CB1005
A13R10 0683-3035 1 R: fxd comp 30K ± 5% 1/4 W 01121 CB3035
A13R11 0764-0024 1 R: fxd met oxide flm 430Ω ± 5% 2 W 07115 C425 obd
A13R12 0686-2025 1 R: fxd comp 2K ± 5% 1/2 W 01121 EB2025
A13R13 0683-3015 1 R: fxd comp 300Ω ± 5% 1/4 W 01121 CB3015
A13R14 0761-0009 1 R: fxd met oxide flm 1.2K ± 5% 1 W 07115 C32 obd
A13R15 0683-4705 3 R: fxd comp 47Ω ± 5% 1/4 W 01121 CB 4705
A13R16 0757-0832 4 R: fxd prec met flm 4. 75K ± 1% 1/2 W 75042 CEC T-O obd
A13R17 2100-1757 R: var ww lin 500Ω ± 10% 1/2 W 75042 Type 506 obd
A13R18* 0757-1042 1 R: fxd met flm 60Ω ±1% 1/4 W 91637 MF-1/8-44 obd
A13R19* 0698-4410 1 R: fxd met flm 49. 9Ω ± 1% 1/2 W 75042 CEC T-O obd
A13R20* 0698-4652 1 R: fxd met flm 5.76K ± 1% 1/4 W 91637 MFF-1/8-32 obd
A13R21 0757-0813 1 R: fxd met flm 475Ω ± 1.0% 1/2 W 91637 MFF-1/2-10 T-1
A13R22 2100-1759 R: var ww lin 2K ± 10% 1/2 W 75042 Type 506 obd
A13R23 2100-1702 1 R: var ww 100Ω ± 10% 1 W 88874 2600 Series obd
A13R24 2100-1758 1 R: var ww lin 1K ± 10% 1/2 W 75042 Type 506 obd
A13R25 0683-1515 1 R: fxd comp 150Ω ± 5% 1/4 W 01121 CB 1515
1205-0033 Heat dissipator semi-conductor for Q1 05820 NF-207 obd
and Q3
A14 03300-66514 Assembly: Synthesizer and voltage -hp-
comparator board
A14C1 0180-0161 C: fxd Ta elect 3.3
Î
F ± 20% 35 vdcw 05397 K3R3J35S
A14C2 0150-0012 2 C: fxd disc cer durez coated 0.01
Î
F 71590 13C Disc obd
± 20% 100 vdcw
A14C3 Not assigned
A14C4 0180-0161 C: fxd Ta elect 3.3
Î
F ± 20% 35 vdcw 05397 K3R3J35S
A14C5, A14C6 0140-0198 5 C: fxd mica 200 pF ± 5% 00853 RDM15F201J3C
A14C7 0140-0197 1 C: fxd mica 180 pF ± 5% 00853 RDM15F181J3C
A14C8 thru 0180-0161 C: fxd Ta elect 3.3
Î
F ± 20% 35 vdcw 05397 K3R3J35S
A14C10
A14C11 0140-0200 1 C: fxd mica 390 pF ± 5% 00853 RDM15F391J3C
A14C12 Not assigned
A14C13 0140-0198 C: fxd mica 200 pF ± 5% 00853 RDM15F201J3C
A14C14 0170-0022 1 C: fxd my 0.1
Î
F ± 20% 600 vdcw 56289 148 P175A
A14CR1 thru 1901-0040 17 Diode: Si 30 mA at +1 V 30 piv 2 pF 2 ns 03877 SG5050 obd
A14CR14
A14CR15, 1901-0025 Diode: Si junction 100 mA at 1 V 100 piv 93332 D3072 obd
A14CR16 12 pF
A14CR17, 1901-0040 Diode: Si 30 mA at 1 V 30 piv 2 pF 2 ns 03877 SG5050 obd
A14CR18
A14CR19 1901-0025 Diode: Si junction 100 mA at 1 V 100 piv 93332 D3072 obd
12 pF
A14CR20 1901-0040 Diode: Si 30 mA at +1 V 30 piv 2 pF 2 ns 03877 SG5050 obd
A14CR21 1901-0033 1 Diode: Si 100 mA at 1 V 180 piv 13 pF 93332 D6238 obd
7-4
