HP 33120A User Manual

WAVEFORMS
Standard Waveforms:
Arbitrary Waveforms:
Waveform Length:
Amplitude Resolution:
Sample Rate:
Non-Volatile Memory:
Sine, Square, Triangle,
Ramp, Noise, DC volts,
Sine(x)/x, Negative Ramp,
Exponential Rise,
Exponential Fall, Cardiac
8 to 16,000 points
12 bits (including sign)
40 MSa / sec
Four (4) 16k waveforms
FREQUENCY CHARACTERISTICS
Sine:
Square:
Triangle:
Ramp:
Noise (Gaussian):
Arbitrary Waveforms:
8 to 8,192 points:
8,193 to 12,287 points:
12,288 to 16,000 points:
Resolution:
Accuracy:
Temperature Coefficient:
Aging:
100
µHz – 15 MHz
100
µHz – 15 MHz
100
µHz – 100 kHz
100
µHz – 100 kHz
10 MHz bandwidth
100
µHz – 5 MHz
100
µHz – 2.5 MHz
100
µHz – 200 kHz
10
µHz or 10 digits
10 ppm in 90 days,
20 ppm in 1 year,
18
°C – 28°C
< 2 ppm /
°C
< 10 ppm / yr
SINEWAVE SPECTRAL PURITY (into 50Ω)
Harmonic Distortion
DC to 20 kHz:
20 kHz to 100 kHz:
100 kHz to 1 MHz:
1 MHz to 15 MHz:
Total Harmonic Distortion
DC to 20 kHz:
Spurious (non-harmonic)
Output (DC to 1 MHz):
Output (> 1 MHz):
Phase Noise:
-70 dBc
-60 dBc
-45 dBc
-35 dBc
< 0.04%
< -65 dBc
< -65 dBc + 6 dB/octave
< -55 dBc in a 30 kHz band
SIGNAL CHARACTERISTICS
Square wave
Rise/Fall Time:
Overshoot:
Asymmetry:
Duty Cycle:
Triangle, Ramp, Arb
Rise/Fall Time:
Linearity:
Settling Time:
Jitter:
< 20 ns
< 4%
1% + 5 ns
20% to 80%
(to 5 MHz)
40% to 60% (to 15 MHz)
100 ns
(typical)
< 0.1% of peak output
< 250 ns to 0.5% of final value
< 25 ns
OUTPUT CHARACTERISTICS
(1)
Amplitude (into 50
Ω): (2)
Accuracy (at 1 kHz):
Flatness
< 100 kHz:
100 kHz to 1 MHz:
1 MHz to 15 MHz:
1 MHz to 15 MHz:
Offset (into 50
Ω):
(3)
Accuracy:
(4)
Output Impedance:
Resolution:
Output Units:
Isolation:
Protection:
50 mVpp – 10 Vpp
± 1% of specified output
(sine wave relative to 1 kHz)
± 1% (0.1 dB)
± 1.5% (0.15 dB)
± 2% (0.2 dB) Ampl ≥ 3Vrms
± 3.5% (0.3 dB) Ampl < 3Vrms
± 5 Vpk ac + dc
± 2% of setting + 2 mV
50 ohms fixed
3 digits, Amplitude and Offset
Vpp, Vrms, dBm
42 Vpk maximum to earth
Short-circuit protected
± 15 Vpk overdrive < 1 minute
(1) Add 1/10th of output amplitude and offset specification
per
°C for operation outside of 18°C to 28°C range
(1-year specification).
(2) 100 mVpp – 20 Vpp amplitude into open-circuit load.
(3) Offset
≤ 2 X peak-to-peak amplitude.
(4) For square wave outputs, add 2% of output amplitude
additional error.
Chapter 8 Specifications
HP 33120A Function / Arbitrary Waveform Generator
298

HP 33120A Specifications

General

Frequency Range	100 µHz to 15 MHz
Waveforms	Sine, Square, Triangle, Ramp, Arbitrary
Amplitude Range	10 mVpp to 10 Vpp into 50 Ohms
Output Impedance	50 Ohms
Interface	GPIB
Function Generator Type	Arbitrary
Power Requirements	100/120/220/240 VAC ±10%, 50/60 Hz, 60 VA max
