HP 33120A User Manual

Front-Panel Number Entry
You can enter numbers from the front-panel using one of three methods.
Use the arrow keys to edit individual digits.
Use the “Enter Number” mode to enter a number with the appropriate units.
Use the knob and the arrow keys to modify the displayed number.
Increments the flashing digit.
Decrements the flashing digit.
Moves the flashing digit
to the right.
Moves the flashing digit
to the left.
Use “Enter” for those operations that do not
require units to be specified (AM Level,
Offset, % Duty, and Store/Recall State).
3

HP 33120A Specifications

General

Frequency Range	100 µHz to 15 MHz
Waveforms	Sine, Square, Triangle, Ramp, Arbitrary
Amplitude Range	10 mVpp to 10 Vpp into 50 Ohms
Output Impedance	50 Ohms
Interface	GPIB
Function Generator Type	Arbitrary
Power Requirements	100/120/220/240 VAC ±10%, 50/60 Hz, 60 VA max
