A front-panel menu tutorial
This section is a step-by-step tutorial which shows you how to use the
front-panel menu. We recommend that you spend a few minutes with
this tutorial to get comfortable with the structure and operation of
the menu.
The menu is organized in a top-down tree structure with three
levels (menus, commands, and parameters). You move down
∨
or up
∧ the menu tree to get from one level to the next. Each of the
three levels has several horizontal choices which you can view by
moving left
< or right > .
• To turn on the menu, press
Shift Menu On/Off .
• To turn off the menu, press
Shift Menu On/Off .
• To execute a menu command, press
Enter .
• To recall the last menu command that was executed,
press
Shift Recall Menu .
• To turn off the menu at any time without saving changes,
press
Shift Cancel .
The menu is organized in a top-down tree structure with three levels.
Menus
Commands
Parameters
2
Chapter 2 Front-Panel Menu Operation
A front-panel menu tutorial
33
