HP 340 G1 - System Board Replacement

3.
Remove the audio/USB board (3) and cable.
Reverse this procedure to install the audio/USB board.
System board
NOTE: The system board spare part kit includes replacement thermal material.
Description Spare part number
Equipped with an Intel Core i7-4500U 1.80-GHz processor (dual core, 15 W), an AMD Radeon
HD 8670M graphics subsystem with 2.0-GB of discrete memory, and the Windows 8 Professional
operating system
746032-601
Equipped with an Intel Core i7-4500U 1.80-GHz processor (dual core, 15 W), an AMD Radeon
HD 8670M graphics subsystem with 2.0-GB of discrete memory, and the Windows 8 Standard
operating system
746032-501
Equipped with an Intel Core i7-4500U 1.80-GHz processor (dual core, 15 W), an AMD Radeon
HD 8670M graphics subsystem with 2.0-GB of discrete memory, and the Windows 7
operating system
746032-001
Equipped with an Intel Core i7-4500U 1.80-GHz processor (dual core, 15 W), an AMD Radeon
HD 8670M graphics subsystem with 1.0-GB of discrete memory, and the Windows 8 Professional
operating system
746026-601
Equipped with an Intel Core i7-4500U 1.80-GHz processor (dual core, 15 W), an AMD Radeon
HD 8670M graphics subsystem with 1.0-GB of discrete memory, and the Windows 8 Standard
operating system
746026-501
Equipped with an Intel Core i7-4500U 1.80-GHz processor (dual core, 15 W), an AMD Radeon
HD 8670M graphics subsystem with 1.0-GB of discrete memory, and the Windows 7
operating system
746026-001
Component replacement procedures
67
