Item Component Spare part number
Equipped with an Intel Core i3-5010U 2.10-GHz processor (dual core, 15 W), a UMA graphics
subsystem, and a non-Windows 8 operating system
796406-001
Equipped with an Intel Core i3-4005U 1.70-GHz processor (dual core, 15 W), a UMA graphics
subsystem, and the Windows 8 Professional operating system
796402-601
Equipped with an Intel Core i3-4005U 1.70-GHz processor (dual core, 15 W), a UMA graphics
subsystem, and the Windows 8 Standard operating system
796402-501
Equipped with an Intel Core i3-4005U 1.70-GHz processor (dual core, 15 W), a UMA graphics
subsystem, and a non-Windows 8 operating system
796402-001
Equipped with an Intel Celeron 3205U 1.50-GHz processor (2.0-MB L3 cache, dual core, 15
W), a UMA graphics subsystem, and the Windows 8 Professional operating system
796404-601
Equipped with an Intel Celeron 3205U 1.50-GHz processor (2.0-MB L3 cache, dual core, 15
W), a UMA graphics subsystem, and the Windows 8 Standard operating system
796404-501
Equipped with an Intel Celeron 3205U 1.50-GHz processor (2.0-MB L3 cache, dual core, 15
W), a UMA graphics subsystem, and a non-Windows 8 operating system
796404-001
(10) RTC battery 718440-001
(11) Fan (includes cable) 746657-001
(12) Heat sink (includes replacement thermal material)
For use only on computer models equipped with a graphics subsystem with
discrete memory
746658-001
For use only on computer models equipped with a graphics subsystem with UMA memory 746659-001
(13) Audio/USB board (includes audio jack, USB port, and cable) 746648-001
(14) Power connector cable 746660-001
(15) Base enclosure () 746649-001
Rubber Kit (not illustrated, includes base enclosure rubber feet) 746669-001
(16) Battery (4-cell, 41-WHr, 2.8-AHr, Li-ion) 752237-001
(17) Memory module (PCL3, 12800, 1600-MHz):
8 GB 693374-001
4 GB 691740-001
2 GB 691739-001
(19) WLAN module:
Atheros AR9485 802.11b g n WiFi Adapter 675794-001
Broadcom BCM943228HMB 802.11abgn 2×2 Wi-Fi Adapter, Broadcom Bluetooth
4.0 Adapter
730668-001
Realtek RT8723BE 802.11bgn 1×1 WiFi + Bluetooth 4.0 Combo Adapter 753077-001
(20) Hard drive (does not include hard drive bracket or hard drive connector adapter):
NOTE: The hard drive bracket and hard drive connector adapter are included in the Hard Drive Hardware Kit, spare part
number 746650-001.
1-TB, 5400-rpm, SATA, 7.0-mm hard drive 778192-001
750-GB, 5400-rpm, SATA, 7.0-mm hard drive 778190-001
18 Chapter 3 Illustrated parts catalog
