4. Remove the optical drive (3).
Reverse this procedure to install the optical drive.
Keyboard
Description Spare part number
For use in Brazil 746019-201
For use in India 746019-D61
For use in Latin America 746019-161
For use in Taiwan 746019-AB1
For use in Thailand 746019-281
For use in the United States 746019-001
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 29).
5. Remove the memory module compartment cover (see Memory module on page 36).
38 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
