1. Close the computer.
2. Turn the computer upside down with the front toward you.
3. Remove the two rubber feet (1).
NOTE: The rubber feet are included in the Rubber Kit, spare part number 746669-001.
4. Remove the ten Phillips PM2.5×6.5 screws (2) that secure the top cover to the base enclosure.
5. Remove the two Phillips PM2.0×2.0 broad head screws (1) in the optical drive bay that secure the top
cover to the base enclosure.
42 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
