NOTE: The following illustration shows the fan/heat sink assembly removal process on a computer
model equipped with an Intel Pentium processor and a graphics subsystem with discrete memory.
NOTE: The following illustration shows the fan/heat sink assembly removal process on a computer
model equipped with an Intel Pentium processor and a graphics subsystem with UMA memory.
Component replacement procedures
85
