NOTE: The following illustration shows the fan/heat sink assembly removal process on a computer
model equipped with an Intel Celeron processor.
The thermal material must be thoroughly cleaned from the surfaces of the heat sink and the system
board components each time the heat sink is removed. Replacement thermal material is included with
the base enclosure, fan/heat sink assembly, processor, and system board spare part kits.
NOTE: The following illustration shows the replacement thermal material locations on a computer
model equipped with an AMD processor.
86 Chapter 4 Removal and replacement procedures
