HP 524pf - How to Order Parts

How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
SPS-IPS 524pf 5E.68402.001
LGD-Q
P16643-001
5E.68402.001
SPS-IPS 524pf 5E.68402.002
INX-Q
P16644-001
5E.68402.002
SPS-IPS 524pf 5E.68402.003
AUO-Q
P16645-001
5E.68402.003
SPS-IPS 524pf 5E.68402.004
BOE-Q
P16646-001
5E.68402.004
Capacitors and connectors are available for purchase from the following EU distributors:
• Farnell: Farnell UK - Electronic Components Distributor
• RS Component: Capacitors | RS Components (rs-online.com)
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part number
Capacitor 470 µF
10*12.5 5K
C706
C707
C801
Farnell; RS
25ZLH470MEFC10X12.5
Connectors by distributor
Component
description
Location
Component
distributor
Distributer part number
DisplayPort (DP)
J1
Farnell
TE 2041441-1
HDMI
J3
Farnell
Molex 47659-1100
USB A type
JB1, JB2
Farnell
Molex 48408-0003
NOTE: The connector may need to be modified to meet functionality, regulatory and safety
requirements if it is not an exact match.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
NOTE: HP continually improves and changes product parts. For complete and current information
about supported parts for your computer, go to http://partsurfer.com, select your country or region, and
then follow the on-screen instructions.
Internal and External Power Supplies are available for purchase from the following EU
distributor: EET https://www.eetgroup.com/en-eu/
