HP 524pf - Rear Cover

11
Rear Cover
No.
Operation
Tool
1
Disassemble STAND
N/A
2
Disassembly VESA
COVER from RC by
pressing the marks.
N/A
3
1. Disassembly screw *
4pcs
2. Take the hinge from
RC.
3. Disassembly RC from
MF & Panel by bending
the side wall.
(1)Screwdriver：
TORQUE 9.0±1
(KG-CM), HOLE
SIZE M4*0.7
(MM) and Screw
Head #2
