Model8756A
Installation
SECTION II
INSTALLATION
2-1.
INTRODUCTION
2-2.
This
section provides installation instruc-
tions
for
the
Model
8756A
Scalar
Network
Analyzer
and
its accessories.
This
section also
includes information
about
initial inspection,
damage
claims,
preparation
for using the instru-
ment, packaging, storage,
and
shipment
2-3.
INITIAL INSPECTION
2-4.
Inspect
the
shipping
container
for
damage.
If
the
shipping
container
or
cushioning
material is
damaged
it
should
be kept until the
contents
of
the
shipment
have
been
checked for
completeness
and
the
instrument
has
been
checked mechanically
and
electrically.
The
con-
tents
of
the
shipment
should
be
as shown
in
Figure
1-1.
Procedures for checking electrical
performance are given in
Section
IV.
If
the
instrument
does
not
pass the electrical perfor-
mance
tests, refer to the adjustments
in
Section
V
of
this manual.
If
a circuit
malfunction
is sus-
pected, refer to troubleshooting information
in
Section VIII.
If
the
instrument
does
not
pass the
above electrical tests,
or
if
the
shipment
contents
are
incomplete,
or
if
there
is
mechanical
damage
or
defect, notify the nearest Hewlett-
Packard
office.
If
the
shipping
container
is
damaged,
or
the
cushioning
material shows
signs
of
stress, notify the carrier as well as the
Hewlett-Packard
office.
Keep
the
shipping
materials for carrier's inspection.
The
HP
office
will arrange for
repair
or
replacement without
waiting for claim
settlement
2-5.
PREPARATION FOR USE
2-6
Power
Requirements
2-7
The
Mode
I 8756A
Seal
a r
Network
Analyzer
requires a power source
of
100,
120,
220,
or
240 Vac, +5% to
-10%,
50
to 60 Hz,
single-phase. Power
consumption
is approx-
imately
100
volt-amps.
2-8.
Line
Voltage
and Fuse
Selection
2-9.
Figure
2-1
illustrates the line voltage selec-
tion
card
and
fuse location
in
the Power Line
Module
on
the
rear
panel
of
the
87
56A
Select
the line voltage
and
fuse as follows:
a.
Measure
the ac line voltage.
b. Refer to Figure
2-1.
At
the
instrument
rear
panel
power line module, select the line
voltage
(100,
120,
220,
or
240 volts) closest to
the voltage you measured
in
step
a.
Note
the available line voltage must be within
+5%
or
-10%
of
the line voltage selection
as shown in Table
2-1.
If
it is not, you
must
use
an
autotransformer
between the power
source
and
the
87
56
A
Table
2-1.
Line Voltage/Fuse Selection
Measured
PC
Selector
Fuse/
ac
Line
Voltage
Board
Position
HP
Part
Number
90 to
105
volts
100
2.0A
2110-0002
108
to
126
volts
120
2.0A
2110-0002
198
to
231
volts
220
1.5A
2110-0043
216 to 252 volts
240
1.5A
2110-0043
c.
Make
sure the correct fuse is installed
in
the fuse holder.
The
required fuse rating for
each line voltage
is
indicated in Table
2-1
and
below the power line
module
on
the
rear
panel
of
the 8756A
2-1
