Introducing the HP 5400R zl2 Switches
Front of the Switch
Introducing the HP 5400R zl2
Switches
Modules (green -
letters
corresponding to
the switch module
slots)
In PoE Mode:
On A module is installed in the switch module slot corresponding to the letter and the module
is undergoing or has passed self test. This also occurs when you install a module when
the switch is already powered on (“hot swap”).
Off A module is not installed in the switch module slot corresponding to the letter.
Blinking
1
On
Blinking
1
Blinking
2
Off
The module status LED flashes very briefly when a module is being hot swapped. If the
LED flashes for a prolonged time, the module in the slot corresponding to the letter has
failed self test or encountered some other fault condition. See chapter 4,
“Troubleshooting” for a more information.
PoE is ok for this slot.
PoE internal fault for this slot.
PoE load fault or insufficient power for this slot.
The module in this slot is not a PoE module.
LED Mode Select
(5 green LEDs)
Act Indicates that the port Mode LEDs are displaying network activity information.
FDx Indicates that the port Mode LEDs are lit for ports that are in Full Duplex Mode.
PoE Indicates which ports are supplying PoE power.
• If the Mode LED is on the port is providing PoE power.
• If the Mode LED is off the port is not providing PoE power.
• If the Link LED is on the port is enabled for PoE.
• If the Link LED is off the port is disabled for PoE.
• If the Link LED is blinking Orange, the port has an error or the port is denied power
due to insufficient power.
Spd Indicates the Port LEDs are displaying the connection speed at which each port is
operating:
• if the Port LED is off, the port is operating at 10 Mbps or at 100 Mbps
• if the Port LED is blinking, the port is operating at 1 Gbps
• if the Port LED is on continuously, the port is operating at 10 Gbps
Usr Reserved for future development
Auxiliary (green/
orange) For more
information see
the Management
and Configuration
Guide for your
switch.
Blinking
green
1
Indicates the switch is processing a USB command file.
On green The switch has successfully finished processing the USB command file.
Blinking
Orange
2
Indicates an error condition.
Off Indicates that no USB device has been inserted, or that the inserted USB device cannot
be recognized, or that no command file can be found on the inserted USB device.
LEDs State Meaning
