4-7
Replacing Components
Replacing the Management Module SD Card
Figure 4-6. Secure Digital installation and removal
3. Slide out the old SD card.
4. Slide in the new SD card being careful not to bend any pins.
5. Reinstall the management module into the switch.
6. Use an equal amount of pressure and push both extractor handles closed
to completely seat the module.
7. Tighten the retaining screws.
