HP 6237B User Manual

Table 6-4. Replaceable Parts
* 6236B/6237B
6-3
REF. MFR. MFR. HP
DESIG. DESCRIPTION TQ* PART NO. CODE PART NO. RS
Printed Circuit Board Assy.
C1 fxd, elect 180µF 50V 2/3 672D047 04200 0180-0634 1
C2 fxd, tant 6.8µF 35V 3 150D685X9035B2 04200 0180-0116 1
C3, 4 fxd, polyester 2200pF 200V 2 292P22292-PTS 04200 0160-0154 1
C7 fxd, elect 1450µF 45V 2 (Type68D) D39532 04200 0180-1893 1
C8, 9 fxd, cer .05µF 400V 6/4 33C17A3-CDH 04200 0150-0052 1
C11 fxd, elect 180µF 50V 672D047 04200 0180-0634
C12 fxd, tant 6.8µF 35V 150D685X9035B2 04200 0180-0116
C13 fxd, polyester .01µF 200V 2 292P10392-PTS 04200 0160-0161 1
C14 fxd, polyester 3300pF 200V 1 292P33292-PTS 04200 0160-0155 1
C17 fxd, elect 1450µF 45V (Type 68D) D39532 04200 0180-1893
C18, 19 fxd, cer .05µF 400V 33C17A3-CDH 04200 0150-0052
C21
6236B fxd, elect 1000µF 12V 1 627D046 04200 0180-0633 1
6237B fxd, elect 180µF 50V 672D047 04200 0180-0634
C22 fxd, tant 6.8µF 35V 150D685X9035B2 04200 0180-0116
C23 fxd, cer .005µF 100V 1 C023B101E502MS27 04200 0160-2639 1
C24 fxd, polyester .01µF 200V 292P10392-PTS 04200 0160-0161
C27
6236B fxd, elect 5600µF 25V 1 (Type 32D) D40018 04200 0180-1921 1
6237B fxd, elect 3000µF 40V 1 32D5278-DQB 04200 0180-1899 1
C28, 29
6236B fxd, cer .05µF 400V 33C17A3-CDH 04200 0150-0052
6237B Not used
C30
6236B Not used
6237B fxd, cer 0.1µF 500V 1 41C92B5-CDH 04200 0160-0269 1
C31
6236B fxd, tant 0.47µF 35V 1 150D474X9035A2 04200 0180-0376 1
6237B fxd, elect 0.15µF 35V 1 T110A154K035AS 61637 0180-0218 1
C32 fxd, mica 330pF 500V 1 obd 72136 0160-2012 1
C33 fxd, elect 490µF 85V 1 (Type 68D) D38618 04200 0180-1888 1
C34 fxd, paper 0.1µF 250Vac 1 PME271-M-610 05917 0160-4065 1
CR1 Diode, Si 1A 200V 13/15 1N5059 1901-0327 7
CR2-7 Diode, Si 17 1N485B 1901-0033 7
CR9, 11, 12, 21 Diode, Si 1A 200V 1N5059 1901-0327
CR22-26 Diode, Si 1N485B 1901-0033
CR28,29,31,32 Diode, Si 1A 200V 1N5059 1901-0327
CR41 Diode, Si 1.5A 200V 3 1N4999 1901-0416 3
CR42, 43 Diode, Si 1N485B 1901-0033
CR44 Diode, stabistor 150mA 15V 2 STB523 03508 1901-0460 2
CR45-47 Diode, Si 1N485B 1901-0033
CR49 Diode, Si 1A 200V 1N5059 1901-0327
CR51, 52 Diode, Si 1.5A 200V 1N4999 1901-0416
CR53, 54
6236B Not used
6237B Diode, Si 1A 200V 1N5059 1901-0327
CR55, 56 Diode, Si 1A 200V 1N5059 1901-0327
CR57 Diode, stabistor 150mA 15V STB523 03508 1901-0460
CR59 Diode, Si 1A 200V 1N5059 1901-0327
