HP 6237B User Manual

Table 6-4. Replaceable Parts (Continued)
Note 1: Alternate part number. See para. 5-43.
6-4
REF. MFR. MFR. HP
DESIG. DESCRIPTION TQ* PART NO. CODE PART NO. RS
CR60 Diode, Si 1N485B 1901-0033
L1, 2, 3 Inductor, ferrite bead 3 56-590-65/4A6 02114 9170-0894 1
(Q2, Q3, CR49)
Q2 SS NPN Si 3 SS1147 (Note1) 04713 1854-0448 3
Q4 SS PNP Si 1 2N2904A 1853-0012 1
Q11 Power PNP Si 1 2N3740 1853-0052 1
Q12 SS NPN Si SS1147 (Note 1) 04713 1854-0448
Q13 SS PNP Si 1 2N4036 1853-0041 1
Q14 SS NPN Si 1 2N2714A 1854-0027 1
Q15 SS NPN Si SS1147 (Note 1) 04713 1854-0448
R1 var. 10k (VOLTAGE ±20V) 2 43X 02582 2100-3461
R2 fxd, film 2.61k 1% 1/8W 1 Type MF4C, T-9 19701 0698-0092 1
R3 fxd, ww 0.1 10% 3W 2 RS-2B 05524 0811-1827 1
R4 fxd, comp 18 5% 1/2W 3 EB1805 01121 0686-1805 1
R6 var. ww 3k 3 Type 110-F4 71450 2100-1823 1
R8 fxd, ww 1.25 1/2% 5W 2 RS5 05524 0811-3384 1
R9 fxd, film 5.49k 1% 1/8W 1 Type MF4C, T-0 19701 0698-3382 1
R10 fxd, film 1.5k 1% 1/8W 1 Type MF4C, T-0 19701 0757-0427 1
R11 fxd, film 110k 1% 1/8W 2 Type MF4C, T-0 19701 0757-0466 1
R12 fxd, film 139 1% 1/8W 3 Type CEA, T-0 07716 0698-4099 1
R13 fxd, comp 15k 5% 1/2W 1 EB 1535 01121 0686-1535 1
R14 fxd, comp 510 5% 1W 1 GB5115 01121 0689-5115 1
R15 fxd, comp 10k 5% 1/2W 2 EB1035 01121 0686-1035 1
R23 fxd, ww 0.25 10% 3W 1 RS-2B 05524 0811-1829 1
R24 fxd, comp 18 5% 1/2W EB1805 01121 0686-1805
R26 var. ww 3k Type 110-F4 71450 2100-1823
R28 fxd, ww 1.25 1/2% 5W RS5 05524 0811-3384
R32 fxd, film 139 1% 1/8W Type CEA, T-0 07716 0698-4099
R33 fxd, film 15k 1% 1/8W 2 Type MF4C, T-0 19701 0757-0446 1
R34 fxd, comp 510 5% 1/2W 1 EB5115 01121 0686-5115 1
R35 fxd, comp 10k 5% 1/2W EB1035 01121 0686-1035
R41 var, 10k 43X 02582 2100-3461
(VOLTAGE +6V or +18V)
R42
6236B fxd, film 8.66k 1% 1/8W 1 Type MF4C, T-9 19701 0698-8076 1
6237B fxd, film 2.87k 1% 1/8W 1 Type MF4C-1 19701 0698-7631 1
R43 fxd, ww 0.1 10% 3W RS-2B 05524 0811-1827
R44 fxd, comp 18 5% 1/2W EB1805 01121 0686-1805
R45
6236B Not used
6237B fxd, film 2k 1% 1/8W 1 CEA993 07716 0757-0283 1
R46 var. ww 3k Type 110-F4 71450 2100-1823
R47
6236B fxd, film 23k 1% 1/8W 1 Type MF4C, T-0 19701 0698-3269 1
6237B Not used
R48
6236B fxd, ww 0.25 1/2% 5W 1 RS5 05524 0811-3383 1
6237B. fxd, ww 0.625 1/2% 5W 1 RS5 05524 0811-3395 1
R49
6236B fxd, film 750 1% 1/8W 1 Type MF4C, T-0 19701 0757-0420 1
6237B Not used
