Table 6-4. Replaceable Parts (Continued)
N
ote
1
:
Al
ternate part num
b
er.
S
ee para.
5
-
43
.
REF. MFR. MFR. HP
DESIG. DESCRIPTION TQ* PART NO. CODE PART NO. RS
R50
6236B fxd, film 330 1% 1/8W 1 Type MF4C, T-9 19701 0698-5663 1
6237B fxd, film 3.83k 1% 1/8W 1 Type MF4C-1 19701 0698-3153 1
R51 fxd, film 110k 1% 1/8W Type MF4C, T-0 19701 0757-0466
R52 fxd, film 139 1% 1/8W Type CEA, T-0 07716 0698-4099
R53 fxd, comp 7.5k 5% 1/2W 1 EB7525 01121 0686-7525 1
R54
6236B fxd, ww 50 5% 10W 1 Type 247E 04200 0811-1902 1
6237B fxd, ww 135 5% 10W 1 Type 247E 04200 0811-1905 1
R55
6236B fxd, comp 2.2k 5% 1/2W 1 EB2225 01121 0686-2225 1
6237B fxd, comp 11k 5% 1/2W 1 EB1135 01121 0686-1135 1
R56 fxd, film 270 1% 1/8W 1 Type CEA, T-0 07716 0757-0269 1
R57 fxd, film 221k 1% 1/8W 1 Type MF4C, T-0 19701 0757-0473 1
R58,59 var. ww 250 2 Type 110 71450 2100-0439 1
R60 fxd, film 15k 1% 1/8W Type MF4C, T-0 19701 0757-0446
R61 fxd, comp 240 5% 1/2W 1 EB2415 01121 0686-2415 1
R62 fxd, film 11k 1% 1/8W 2 Type MF4C, T-0 19701 0757-0443 1
R63 fxd, film 3.6k 2% 1/8W 1 Type MF4C, T-0 19701 0757-0937 1
R64 fxd, film 11k 1% 1/8W Type MF4C, T-0 19701 0757-0443
R65 fxd, film 16.2k 1% 1/8W 1 Type MF4C, T-0 19701 0757-0447 1
R66 fxd, film 470 1% 1/4W 1 Type MF52C, T-0 19701 0698-3506 1
R67
6236B fxd, ww 135 5% 3W 1 Type 242E 04200 0812-0112 1
6237B fxd, ww 220 5% 2W 1 Type BWH 75042 0811-1763 1
R68
6236B fxd, ww 250 5% 3W 1 Type 242E 04200 0811-1219 1
6237B fxd, ww 490 5% 3W 1 Type 242E 04200 0811-1801 1
R69
6236B fxd, ww 100 5% 10W 1 Type 247E 04200 0811-1903 1
6237B fxd, ww 150 5% 10W 1 Type 247E 04200 0811-1906 1
R70
6236B fxd, ww 40 5% 5W 1 Type 243E 04200 0812-0083 1
6237B fxd, ww 75 5% 5W 1 RS5 05524 0812-0097 1
R71 fxd, film 471 1% 1/8W 1 Type CMF-55-1, T-1 05524 0698-5514 1
R72 fxd, comp 33k 5% 1/2W 1 EB3335 01121 0686-3335 1
R73,6236B Not used
6237B fxd,comp 1.1M 5% 1/2W 1 EB1155 01121 0686-1155 1
R74,6236B (jumper installed)
6237B fxd, film 6.98k 1% 1/8W 1 Type CMF-55-1, T-1 05524 0698-4470 1
R76 fxd, ww 10k 5% 3W 1 RS-2B 05524 0811-1816 1
S3 slide switch, dual DPDT 1 28480 3101-1914 1
T1 Power Transformer 28480 06236-80091
U1-3 Dual op amp, IC 3 CA 3458T (Note 1) 02735 1826-0092 3
U4 Operational amp, IC 1 LM301AH 27014 1820-0223 1
VR1 Diode, zener 6.2V 1 1N825 1902-1221 1
VR2 Diode, zener 9.09V 1 SZ10939-170 04713 1902-3149 1
VR3 Diode, zener 7.5V 1 1N4353B 1902-0650 1
Z1 Resistor network 1 28480 1810-0217
