HP
8481A/82A/83A
08481-90049
6.
Using
tweezers,
position
the
ends
of
the
gold
wires
over
the
electrical
pads.
DO
NOT
tighten
clamp
screw
6
excessively
or
the
FET
circuit
may
be
broken.
Caution
«
Place
and
hold
plastic
clamp
16
over
the
gold
wires.
As
you
tighten
the
clamp
screw,
watch
the
compression
spring.
Tighten
the
clamp
screw
7
only
until
the
spring
coils
touch.
Any
further
tightening
could
damage
the
FET
circuit.
Place
the
upper
chassis
in
position
and
insert
cap
screws
1,
2,
10,
and
13.
Tighten
1,
2,
3,
and
4.
Tighten
10,
11, 12,
and
13.
Place
the
plastic
shells,
magnetic
shields,
and
the
chassis
together
as
shown
in
fi
gure
1.
Snap
the
plcistic
shells
together.
7.
8.
9.
10.
11.
26
