Chapter 8, Programming The Call Processing Subsystem
Using the Call Processing Subsystem’s Remote User Interface
Using the Call Processing Subsystem’s Remote User Interface
In order to use the Call Processing Subsystem’s Remote User Interface, a mobile
station must be powered on, and connected to the Test Set.
Connecting a Mobile Station
Figure 32, "Connecting a Mobile Station to the Test Set," on page 465 shows a
typical example of how to connect a mobile station to the Test Set. You may need
a special fixture to access the mobile station’s antenna, audio in, and audio out
signals. These fixtures are available from the mobile station’s manufacturer.
If any audio testing is to be done on the mobile station, the audio input
(microphone input) to the mobile station and the audio output (speaker output)
from the mobile station must be connected to the Test Set. If no audio testing is to
be done only the antenna needs to be connected to the Test Set.
