11. If it is necessary to replace the display back cover:
a. Remove the display bezel.
b. Remove the display panel.
c. Remove the six Phillips PM2.0×2.9 broad head screws (1) that secure the back cover to
the display hinges.
d. Remove the back cover (2).
NOTE: The back cover is available using spare part numbers L14908-001 (in chalkboard gray nish)
and L14911-001 (in delicate orange nish), and includes the webcam/microphone module cable and
wireless antenna cables and transceivers.
Component replacement procedures 39
