HP Chromebook 14 User Manual

16. If you need to remove the antenna cables, remove the cables from the clips on the inside of the cover
(1), and then peel the antennas o the cover to remove them (2).
Antenna cables are available as spare part number M00435-001.
The display back cover is available as spare part number M35755-001.
Reverse this procedure to reassemble and replace the display assembly.
Keyboard with top cover
The top cover with keyboard remains after removing all other spare parts from the computer. In this section,
the rst table provides the main spare part number for the top cover/keyboards. The second table provides
the country codes.
Table
5-13 Keyboard with top cover descriptions and part numbers
Description Spare part number
Keyboard with top cover, backlit, with ngerprint sensor M35770-xx1
Keyboard with top cover, backlit, without ngerprint sensor M35769-xx1
Keyboard with top cover, not backlit, without ngerprint sensor M35772-xx1
Keyboard with top cover, not backlit, with ngerprint sensor M35771-xx1
Table 5-14 Spare part country codes
For use in country or region Spare part number For use in country or region Spare part number
Belgium -A41 The Netherlands -B31
Denmark, Finland, and Norway -DH1 Spain -071
France -051 United Kingdom -031
Germany -041 United States -001
Italy -061
Component replacement procedures 43

HP Chromebook 14 Specifications

General

Display Size	14 inches
Operating System	Chrome OS
Wireless	802.11a/b/g/n/ac
Storage	16GB eMMC
Battery Life	Up to 9 hours
Display Resolution	1366 x 768
Bluetooth	Bluetooth 4.0
Ports	1 x Headphone/Microphone Combo
RAM	2GB, 4GB
Weight	3.4 lbs (1.54 kg)
Graphics	Intel HD Graphics
