To replace the control panel, follow steps 1 through 4 above in reverse order.
Memory-card assembly removal and replacement (HP Color
LaserJet CM1017 MFP only)
Use the following procedure to remove the memory-card assembly.
1. Remove one screw from the right cover assembly.
1 One screw
2. Open the front door.
100 Chapter 5 Removal and replacement ENWW
