Functional tests (SERVICE ONLY)
Engine-test print
The engine-test print confirms whether the printing function (as performed by the DC controller) is
operating correctly.
1. Verify the printer is in Ready mode.
2. Remove the screw from the test-switch cover (1) on the back panel of the MFP, and then
remove the cover.
1
Figure 6-2 Engine-test switch cover
ENWW Functional tests (SERVICE ONLY) 145
