Description Part number Table and page
COVER, CASSETTE, LEFT RC2-1691-000CN External panels and covers
on page 169
COVER, CONTROLLER RC1-5228-000CN External panels and covers
on page 169
COVER, FACE-DOWN RC2-1672-000CN External panels and covers
on page 169
COVER, FACE-UP, REAR RC2-1675-000CN External panels and covers
on page 169
COVER, LEFT RC1-5183-000CN External panels and covers
on page 169
COVER, UPPER, LEFT RC2-1664-000CN Upper cover assembly
on page 171
COVER, UPPER, RIGHT RC2-1663-000CN Upper cover assembly
on page 171
DC CONTROLLER PCB ASSEMBLY RM1-4366-000CN Internal components (3 of 3)
on page 177
ELECT.TRANSPORT BELT ASSEMBLY RM1-1885-020CN Internal components (2 of 3)
on page 175
FACE-UP PAPER DELIVERY ASSEMBLY RM1-4312-000CN Assembly locations (1 of 3)
on page 163
FACE-UP PAPER DELIVERY ASSEMBLY RM1-4312-000CN Face-up paper delivery
assembly on page 185
FERRITE BEAD (COLUMN AREA) 9170–2120 Internal components (1 of 3)
on page 173
FERRITE BEAD (FORMATTER AREA) 9170–2083 Internal components (1 of 3)
on page 173
FLAT FLEX CABLE - DCC FORMATTER Q6456–60101 Internal components (3 of 3)
on page 177
FLAT FLEX CABLE, MEMORY-CARD ASSEMBLY CB394–60104 Memory-card reader
assembly on page 187
FORMATTER (CM1015) CB394–67902 Internal components (3 of 3)
on page 177
FORMATTER (CM1017) CB395–67902 Internal components (3 of 3)
on page 177
FRONT DOOR ASSEMBLY RM1-4314-000CN External panels and covers
on page 169
FUSER ASSEMBLY RM1-4310-000CN
(110v) or
RM1-4313-000CN (220v)
Assembly locations (1 of 3)
on page 163
LEVER, LINK RC1-5272-000CN External panels and covers
on page 169
LID, CONTROLLER RC1-5229-000CN External panels and covers
on page 169
Table 7-19 Alphabetical parts list (continued)
196 Chapter 7 Parts and diagrams ENWW
