Description Part number Table and page
MAIN DRIVE ASSEMBLY RM1-1895-120CN Assembly locations (2 of 3)
on page 165
MEMORY-CARD READER ASSEMBLY Q7821-67901 (CM1017
only)
Memory-card reader
assembly on page 187
PANEL FRONT (TRAY 2 FRONT COVER) RC1–5346–000CN External panels and covers
on page 169
PAPER PICK-UP FEEDER ASSEMBLY RM1-1923-000CN Assembly locations (1 of 3)
on page 163
PAPER PICK-UP FEEDER ASSEMBLY RM1-1928-030CN Paper pick-up feeder
assembly (tray 2) on page 181
PLATE, REAR RC2-1687-000CN External panels and covers
on page 169
RIGHT COVER ASSEMBLY RM1-1858-000CN External panels and covers
on page 169
RIGHT FRONT PHOTO MEMORY COVER CB395–67910 External panels and covers
on page 169
ROLLER, FACE-UP RC2-1682-000CN External panels and covers
on page 169
ROLLER, PAPER PICK-UP RC1-5440-000CN Paper pick-up feeder
assembly (tray 2) on page 181
ROLLER, PAPER PICK-UP RC1-5440-000CN Paper pickup feeder
assembly (Tray 3) on page 183
SCANNER ASSEMBLY (CM1015) CB394–67901 Scanner assembly
on page 189
SCANNER ASSEMBLY (CM1017) CB395–67901 Scanner assembly
on page 189
SCANNER LID CB394-60106 Scanner assembly
on page 189
SCREW RS, M3x8 XA9-1500-000CN External panels and covers
on page 169
SCREW, TAPPING, TRUSS HEAD M4x10 XB4-7401-005CN External panels and covers
on page 169
SEPARATION ASSEMBLY RM1-1922-000CN Cassette on page 179
SHAFT, FRONT DOOR ARM RC1-5194-000CN External panels and covers
on page 169
SHEET, LEFT PANEL, LOWER RC1-5204-000CN External panels and covers
on page 169
TRAY, FACE-UP RC2-1671-000CN External panels and covers
on page 169
UPPER COVER ASSEMBLY RM1-4311-000CN Assembly locations (2 of 3)
on page 165
Table 7-19 Alphabetical parts list (continued)
ENWW Alphabetical parts list 197
