8. Unthread the thermistor wires from the wiring harness.
9. At the top of the MFP, remove three screws from the fuser chassis: the two inside screws on the
back of the fuser, and one screw on the side.
1 Two inside screws on the back of the fuser chassis
2 One screw on the side of the fuser chassis
88 Chapter 5 Removal and replacement ENWW
