10. Gently rocking it if necessary, roll the fuser forward to remove.
Use the following procedure to replace the fuser.
1. Insert the front-facing part of the fuser into the fuser cradle.
2. Rotate the rear-facing part of the fuser slightly up, and then push the front of the fuser into place
so that the rear rotates down onto the guide pins on the printer frame.
3. Complete the replacement by following steps 1 through 9 above in reverse order.
NOTE When replacing the right cover, align the tabs on the upper edge of the right cover
and lower edge of the face-up cover with their respective slots.
ENWW Removal and replacement procedures 89
