Installation and Setup
Installation
A-4
The defibrillator connector accepts external paddles, external adhesive pads, or
internal paddles.
Connecting Paddles or Pads To connect external paddles, internal paddles, or
adhesive pads to the defibrillator, perform the following steps:
1 Slide the paddle connector lock on the paddles plug to the unlock position. To
do this, push the lock towards the top of the connector.
2 Insert the paddles/pads adaptor cable plug into the paddles connector on the
defibrillator, as shown in Figure 7-1 on page 7-1.
3 Slide the paddle connector lock to the lock position, to latch the plug in place.
