Installation and Setup
Installation
A-3
Figure 1-1
Installing the Battery
Loading the Recorder Paper
The defibrillator recorder uses two-inch wide, thermal paper (HP 40457C/D). To
load the paper, refer to the procedure in “Changing the Recorder Paper” (page 7-1).
Connecting Paddles and Patient Cables
The defibrillator has a paddles connector for attaching pads/paddles sets and an
ECG Input connector for attaching leads.
Paddles Connector
Battery
Battery compartment
Battery plug
Battery
