Installation and Setup
Installation
A-6
3 wire = RA, LA, LL
5 wire = RA, RL, LA, LL + V (C)
Connecting a Patient Cable The 3-wire or 5-wire patient cable connects to the ECG
Input connector located on the front of the defibrillator, behind the carrying handle.
The patient cable plug has 6- , 8-, or 12-pins. Before installing the patient cable,
make sure that the pin count of the patient cable plug matches the pin count of the
ECG Input connector. To install the patient cable:
1 Align the keyed cable plug with the slot in the ECG Input connector. See Figure
1-3 on page A-7.
2 Push the cable plug firmly into the ECG Input connector.
When a lead is selected for monitoring, the message LEADS OFF appears on the
display if the patient cable falls off or is incorrectly connected. Also, a dashed line
appears on the display in place of an ECG trace.
NOTE
NOTE
