HP Compaq 6000 Pro Quickspecs

NIC Intel 82567LM Gigabit Network Connection (integrated on system board) X X
Broadcom NetXtreme Gigabit Ethernet Plus PCIe NIC X X
Broadcom NetXtreme Gigabit Ethernet Plus (DASH 1.1) PCIe NIC Card
(with cable for internal USB header)
X X
Intel Gigabit CT Desktop NIC X X
Wireless HP 802.11 b/g/n Wireless PCIe x1 card (full height bracket) X
HP 802.11 b/g/n Wireless PCIe x1 card (low profile bracket) X
Modem LSI PCIe x1 56K International SoftModem X X
Graphics Integrated Intel Graphics Media Accelerator 4500 X X
ATI Radeon HD 4650 (1 GB DH) PCIe x16 Graphics Card X
ATI Radeon HD 4550 Dual Head PCIe x16 Graphics Card X X
NVIDIA Quadro NVS 290 PCIe x1 Graphics Card X X
NVIDIA Quadro NVS 290 (256MB DH) PCIe x16 Graphics Card X X
NVIDIA Quadro NVS 295 (256MB DH) PCIe x16 Graphics Card* X X
NVIDIA NVS 300 PCIe x16 512MB Graphics Card X X
NVIDIA NVS 300 PCIe x1 512MB Graphics Card X X
NVIDIA GeForce 310 DP PCIe x16 Graphics Card X X
HP ADD2 SDVO PCIe DVI-D adapter X X
HP DisplayPort to VGA Adapter X X
HP DisplayPort to DVI-D Adapter X X
* When ordered with an Nvidia Quadro NVS 295 card, the PC is shipped with two
DisplayPort to VGA Adapters. When an Nvidia Quadro NVS 295 card is purchased as an
after-market option, it comes with two DisplayPort to DVI-D Adapters.
Audio Integrated High Definition audio with Realtek ALC261 codec (all ports are stereo) X X
Microphone and Headphone front ports * X X
Line-out and Line-In rear ports * X X
Multistreaming capable * X X
Internal Speaker X X
HP Thin USB Powered Speakers (optional) X X
* Re-taskable ports; see technical specifications page 21.
QuickSpecs
HP Compaq 6000 Pro Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13411 North America — Version 24 — October 19, 2011 Page 13

HP Compaq 6000 Pro Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	C0
Processor cache	6 MB
Processor cores	2
Processor model	E8500
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3.16 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Processor core voltage (AC)	0.850/1.3625 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Platform	PC
LightScribe	Yes
Power supply type	AC/DC
Security features	TPM 1.2
External drive bays	2 x 5.25\
Internal drive bays	2 x 3.5\
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	Realtek ALC261
Motherboard chipset	Intel® Q43
Audio output channels	2.0 channels
Memory slots	4x DIMM
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 2 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® GMA 4500
On-board graphics card family	Intel® GMA
Operating system installed	Windows 7 Professional
USB 2.0 ports quantity	10
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Power supply	320 W
Processor code	SLAPK
Processor ARK ID	33911
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
