HP Compaq 6000 Pro Quickspecs

Dedicated Video Memory : Memory owned and locked for graphics use as reported by
the OS. (Preallocated)
System Video Memory : System memory locked and dedicated for graphics use.
Shared System Memory : Memory dynamically allocated for Graphics use
HW Video Decode Hardware Accelerated decode for MPEG2 encrypted video; support for PAVP Lite
(default) and Heavy ( or Paranoid) modes
Maximum Color Depth 32 bits/pixel
Maximum Vertical
Refresh Rate
85 Hz at up to 1920x1440, 75 Hz at 2048x1536. Varies with mode and configuration.
See table below.
Multi-display Support Dual monitor support facilitated via one VGA port and one DisplayPort integrated on the
back plane of the system board and presented as part of the rear I/O set of interfaces.
DVI supported via optional HP DisplayPort to DVI-D adapter.
Graphics/Video API
Support
Microsoft DirectX® 10, OpenGL® 1.5 (OpenGL® 2.0 available in a driver update)
Resolutions Supported
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP.
Maximum Refresh Rate (Hz)
Resolution Analog Connection Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A 60 *
* Only supported when using a DisplayPort connection
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital connections.
ATI Radeon HD 4650 (1 GB
DH) PCIe x16 Graphics
Card (FH Only)
Bus type PCI Express (x16 lanes)
Maximum vertical refresh rate 85 Hz
Display support Integrated 400 MHz RAMDAC
Display max resolution 2560 x 1600 digital, 2048 x 1536 analog
Board display options Supports two displays through any combination of two of the three output
ports.
Board configuration Specification Description
QuickSpecs
HP Compaq 6000 Pro Business PC
Technical Specifications - Graphics
DA - 13411 North America — Version 24 — October 19, 2011 Page 30

HP Compaq 6000 Pro Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	C0
Processor cache	6 MB
Processor cores	2
Processor model	E8500
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3.16 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Processor core voltage (AC)	0.850/1.3625 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Platform	PC
LightScribe	Yes
Power supply type	AC/DC
Security features	TPM 1.2
External drive bays	2 x 5.25\
Internal drive bays	2 x 3.5\
Networking features	Gigabit Ethernet
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	Realtek ALC261
Motherboard chipset	Intel® Q43
Audio output channels	2.0 channels
Memory slots	4x DIMM
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 2 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Total storage capacity	500 GB
Discrete graphics card model	Not available
On-board graphics card model	Intel® GMA 4500
On-board graphics card family	Intel® GMA
Operating system installed	Windows 7 Professional
USB 2.0 ports quantity	10
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Power supply	320 W
Processor code	SLAPK
Processor ARK ID	33911
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
