Page #18 background imageLoading...
Page #18 background image
Unit Environment and Operating
Conditions
Microtower
Small Form Factor
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is
operated within the specified operating range.
Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are subject to each other's re-
circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign
matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the enclosure,
and the same operating guidelines listed above will still apply.
Temperature Range
Operating: 50° to 95° F (10° to 35° C)
*
Non-operating: -22° to 140° F(-30° to 60° C)
Relative Humidity
Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating: 10,000 ft (3048 m)
Non-operating: 30,000 ft (9144 m)
* Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight.
Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Microtower
Small Form Factor
Power Supply
320-watt BTX power
supply - Active PFC
320-watt 89%
efficient
*
BTX power
supply - Active PFC
240-watt BTX power
supply - Active PFC
240-watt 89%
efficient
*
BTX power
supply - Active PFC
Operating Voltage Range
100-240VAC 100-240VAC 100-240VAC 100-240VAC
Rated Voltage Range
115V/230V 115V/230V 115V/230V 115V/230V
Rated Line Frequency
50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Operating Line Frequency Range
47-63 Hz 47-63 Hz 47-63 Hz 47-63 Hz
Rated Input Current
5.5A 5.5A
4A 4A
Power Supply Fan
Variable speed fan Variable speed fan Variable speed fan Variable speed fan
Power Cord Length
6 ft (1.83 m) 6 ft (1.83 m)
ENERGY STAR Compliant
X X
FEMP Standby Power Compliant
(<1W in S5 - Power Off)
**
X X X X
Power Consumption in ENERGY
STAR Mode - Suspend to RAM (S3)
(Instantly Available PC)
<4W <3W <4W <3W
* Energy efficient power supply is a requirement for ENERGY STAR qualification in conjunction with a select range of processors and
modules
** Power consumption in the Off/Apparent Off mode is measured and reported with the network interface controller "Wake on LAN"
feature disabled in F10 Setup (default is "enabled").
QuickSpecs
HP Compaq 6000 Pro Business PC
Technical Specifications
DA - 13411 North America — Version 24 — October 19, 2011
Page 18
