HP Compaq 6000 Pro

Environmental Operating temperature 32° to 131°F (0° to 55° C)
Operating humidity 131° F (55° C) with 5% to 95% non-condensing
humidity
Dimensions 2.75 in x 4.13 in (7 cm x 10.5 cm), low profile compatible
Management capabilities ACPI, WOL and DMI 2.0, PXE 2.0, WfM 2.0, Broadcom mgmt utility, ASF2.0,
DASH 1.0 and DASH 1.1 profiles
HP 802.11b/g/n Wireless
PCIe x1 Card
Dimensions (L x H) 3.3 x 4.7 inches (8.5 x 12 cm)
Weight 0.08 pounds (40 g)
Controller Ralink RT2790
System interface PCIExpress x1
Network standard 802.11 b/g/n
Frequency band 2.400 - 2.497 GHz
Operating temperature 14° to 149°F, operating (-10° to 65°C, operating)
Storage temperature -40° to 176°F, non-operating (-40° to 80°C, non-operating)
Humidity 10-90% operating
5-95% non-operating
Operating voltage 3.3V +/- 9%
12V +/- 8%
Power consumption Platform/WLAN Mode Power Consumption
Maximum Power
Consumption
10 Watts
Transmit Only 4 Watts maximum averaged power over 1 second
Transmit Packet or Active
Scanning
1000 mA peak current for 100 microseconds or
longer
Receive Only Mode or Idle
without IEEE PSP mode
enabled
3 Watts maximum averaged over 1 second
Idle, with IEEE PSP mode
enabled
1.0 Watts maximum averaged over 1 second
Transmit Disabled (turned
off in software)
50 mW maximum, averaged over 1 second
Platform in S3 or S4
(power removed from Low
Profile PCI Express Card)
5 mW maximum, averaged over 1 second
Output power
(approximately)
802.11b modes 802.11g modes EWC modes
+19 dBm +/- 1.0 dB
maximum
+17 dBm +/- 1.0 dB
maximum
+17 dBm +/- 1.0 dB
maximum (total
power in all transmit
chains)
Receive sensitivity Mode Data rate Sensitivity
802.11b 1 Mbps -94 dBm
802.11b 11 Mbps -85 dBm
QuickSpecs
HP Compaq 6000 Pro Business PC
Technical Specifications - Communications
DA - 13411 North America — Version 24 — October 19, 2011 Page 25
