HP Compaq 6530s

Front components
Item Component Function
(1) Media Card Reader Supports the following optional digital card formats:
●
Memory Stick (MS)
●
Memory Stick Pro (MSP)
●
MultiMedia Card (MMC)
●
MultiMedia Card (MMC) Plus
●
Secure Digital (SD) Memory Card
●
Secure Digital High Capacity (SDHC) Memory Card
●
xD-Picture Card (XD)
●
xD-Picture Card (XD) Type H
●
xD-Picture Card (XD) Type M
(2) Drive light
●
Blinking turquoise. The hard drive or optical drive is
being accessed.
●
Amber: HP 3D DriveGuard has temporarily parked the
hard drive.
(3) Audio-out (headphone) jack Connects optional powered stereo speakers, headphones,
ear buds, a headset, or television audio.
(4) Internal microphone Records sound.
(5) Audio-in (microphone) jack Connects an optional computer headset microphone,
stereo array microphone, or monaural microphone.
Right-side components
Item Component Function
(1) USB ports (2) Connect optional USB devices.
12 Chapter 2 External component identification
