Display assembly
NOTE: All display assembly spare part kits include 2 WLAN antenna transceivers and cables.
Description Spare part number
For use only with HP Compaq 6535s Notebook PC models
14.1-inch, WXGA BrightView display assembly with camera
493155-001
14.1-inch, WXGA BrightView display assembly 493154-001
14.1-inch, WXGA display assembly with camera 493152-001
14.1-inch, WXGA display assembly 493151-001
For use only with HP Compaq 6530s and 6531s Notebook PC models
14.1-inch, WXGA BrightView display assembly with camera
491643-001
14.1-inch, WXGA display assembly with camera 491642-001
14.1-inch, WXGA BrightView display assembly 491641-001
14.1-inch, WXGA display assembly 491640-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 46).
5. Remove the following components:
a. Switch cover (see
Switch cover and keyboard on page 57)
b. Keyboard (see
Switch cover and keyboard on page 57)
c. Speakers (see
Speakers on page 61)
Remove the display cable:
1. Turn the computer right-side up, with the front toward you.
2. Open the computer as far as possible.
3. Disconnect the display panel cable (1) from the system board.
CAUTION: There is a ground loop off the display panel cable that is secured to the left hinge. Be
sure you do not pull or damage the cable.
4. Disconnect the camera and microphone module cables (2) from the system board, and then
remove the cables from the routing path (3).
62 Chapter 4 Removal and replacement procedures
