Item Description Spare part number
For use in Thailand 491653-281
For use in the United States 491653-001
(5) Speakers
For use only with HP Compaq 6535s Notebook PC models 493173-001
For use only with HP Compaq 6530s and 6531s Notebook PC models 491656-001
(6) Top cover (includes TouchPad board and cable, and TouchPad button board and cable) 491632-001
(7) Modem module cable (includes RJ-11 connector)
(8) TouchPad spared with top cover
(9) Plastics Kit (see Plastics Kit on page 25 for more Plastics Kit spare part information):
For use only with HP Compaq 6535s Notebook PC models 493175-001
For use only with HP Compaq 6530s and 6531s Notebook PC models 491253-001
(9a) ExpressCard slot bezel
(9b) WLAN module compartment cover
(9c) Hard drive bay cover
(9d) Memory module compartment cover
(10)
TouchPad cable spared with top cover
(11) TouchPad bracket spared with top cover (included in the Top cover kit, which also includes
the TouchPad button board actuators, which are not illustrated)
(12) Modem 461749-001
(13) Heat sink (includes replacement thermal material)
For use only with HP Compaq 6535s Notebook PC models 493174-001
For use only with HP Compaq 6531s Notebook PC models 491980-001
For use only with HP Compaq 6530s Notebook PC models 496679-001
(14) Fan
For use only with HP Compaq 6535s Notebook PC models 493177-001
For use only with HP Compaq 6530s and 6531s Notebook PC models 490324-001
(15) Broadcom Bluetooth module
For use in all countries and regions except Japan and Asia Pacific 398393-002
For use only in Japan and Asia Pacific 450066-001
(16) USB connector and cable
Cable Kit for use only with HP Compaq 6535s Notebook PC models (not illustrated; see Cable
Kit on page 26 for more Cable Kit spare part number information)
497616-001
Cable Kit for use only with HP Compaq 6530s and 6531s Notebook PC models (not illustrated;
see
Cable Kit on page 26 for more Cable Kit spare part number information)
491662-001
(17) System board (includes replacement thermal material and the ExpressCard assembly)
Computer major components 19
