HP COMPAQ 8000 User Manual

12. Position the hard drive so that the top of the hard drive is up against the top of the carrier (1) so
that the circuit board on the bottom of the hard drive does not come in contact wit the tabs on the
bottom of the carrier, then slide the new hard drive into the carrier (2).
CAUTION: Do not allow the circuit board on the bottom of the hard drive to scrape along the tabs
on the bottom of the carrier when sliding the hard drive into the carrier. Doing so can cause
irreparable damage to the hard drive.
Figure 2-18 Sliding the Hard Drive into the Carrier
13. Set the hard drive down into the bottom of the carrier (1), then replace the four guide screws on
the sides of the carrier to secure the drive in the carrier (2).
Figure 2-19 Lowering the Hard Drive and Replacing the Guide Screws
24 Chapter 2 Hardware Upgrades ENWW

HP COMPAQ 8000 Specifications

General

Chipset	Intel Q45 Express
Audio	Integrated High Definition audio
Processor	Intel Core 2 Duo
RAM	Up to 16 GB DDR3
Storage	HDD or SSD
Graphics	Integrated Intel Graphics Media Accelerator
Operating System	Windows 7, Windows Vista, Windows XP
Network	Integrated Gigabit Ethernet
Ports	1 VGA, 1 DisplayPort, 1 serial, audio in/out
Optical Drive	DVD-ROM
Form Factor	Small Form Factor
Expansion Slots	1 PCI, 2 PCIe x1, 1 PCIe x16
