HP Compaq dc7600 MT Hardware Reference Guide

2–26 www.hp.com Hardware Reference Guide
Hardware Upgrades
✎
If you are installing a third optional drive in the bottom 5.25-inch
drive bay, you must also install an expansion card with an IDE
controller and data cable (not supplied) because the secondary IDE
controller supports only two drives.
✎
If you are installing a third optional drive, you may need to remove
the strap that bundles the extra power connectors.
6. Connect the power and signal cables to the rear of the drive.
Connecting the Drive Cables
7. Remove the appropriate bezel blank from the subpanel inside the
front bezel. See the “Removing Bezel Blanks” section for more
information.
8. Replace the computer access panel and front bezel.
9. If you normally lock the Smart Cover Lock, use Computer Setup
to relock the lock and enable the Smart Cover Sensor.
10. Reconfigure the computer, if necessary. Refer to the Computer
Setup (F10) Utility Guide on the Documentation and Diagnostics
CD for instructions about using Computer Setup.

HP Compaq dc7600 MT Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Form Factor	Microtower
Processor	Intel Pentium 4 or Intel Celeron D
Chipset	Intel 945G Express
Hard Drive	40 GB to 160GB SATA
Optical Drive	DVD-ROM, DVD+/-RW
Graphics	Integrated Intel Graphics Media Accelerator 950
Networking	Integrated 10/100/1000 Ethernet
Ports	Serial, parallel, VGA, audio in/out
Operating System	Windows XP Professional, Windows XP Home
USB Ports	8 USB 2.0 (2 front, 6 rear)
