Service Reference Guide 483941-001 6–27
Removal and Replacement Procedures— Microtower (MT)/Small Form Factor (SFF) Chassis
6. Press the latch 1 .
7. Slide the drive to the right of the bay 2.
Removing the Hard Drive
8. To install a hard drive, reverse the above procedure.
9. Connect the power cable 1 and data cable 2 to the hard drive.
Connecting the Power Cable and Data Cable
